6500 Nits Big P5 Outdoor LED Billboard Electronic , Front Access Led Screen Advertising
Description
1. SMD3-IN-1 technology are used for indoor LED display
2. Wide view angle:140 inhorizonal and 140 in vertical
3. Special design and advanced SMT technology improves the heat dissipation
4. With high fresh rate controller, guarantee that no scan line when taking photos
5. Regular shape and special shape(such as curve,round) can be designed
6. Easy for assembleing and connection with the connector added
7. High color uniformity and clear image can bring you a vivid audio visual effect
8. Both front access and rear access areavailable
Advantage
1. Wide viewing angle: Viview led display show clear pictures or image without mosaics even when audiences see it from a small viewing angle;
2. Rich colors: With three basic colors (red, green and blue), 256-level gradation of each color, and form 16777216 kinds of colors;
3. Adjustable brightness: Viview LED screen brightness can be adjusted automatic and manual according to environment light;
4. Good color blending: Display clear, exquisite, nature color video even at close distance;
5. Wide range of display content: Viview led wall can easily to display txt documents, doc documents, pictures (BMP/JPG/GIF/PCX…..) and video (MPG/MPEG/MPV/MPA/AVE/VCD/SWF/RM/RA/RMJ/ASF)
6. Viview led display usage range: Governmental plazas, Large-scale entertainment plazas, business and commercial centers, playground, station, airport and so on.
Specification
| Pixel Pitch | 5mm |
| Pixel Density | 40000dots/sqm |
| Color Configuration | 1R1G1B |
| LED Package | SMD2727 |
| Module Size | 320mm x 160mm |
| Module Resolution | 64dots x 32dots |
| Drive Mode | 1/8 Scan |
| Standard Cabinet Size | 960mm x 960mm |
| Cabinet Weight | 45KG |
| Brightness | ≥6500 cd/sqm |
| Viewing Distance | 5m-50m |
| Viewing Angle | H: 140°; V:140° |
| Refresh Rate | 2000HZ, adjustable by software |
| Frame Rate | 120frame/s |
| Grey Scale | 16.7M colors(Synchronized) |
| Color Temperature | R.G.B brightness 256 level adjustable |
| Power Input | AC110V/ 220V ±10％, 50HZ |
| Max Power Consumption | 800W/sqm |
| Ave. Power Consumption | 300W/sqm |
| Storage Temperature | -30℃~+70℃ |
| Working Temperature | -20℃~+50℃ |
| Blind Spot Rate | <1/10000 |
| MTBF | >10,000 Hours |
| Life Span | >100,000 Hours |
| Waterproof Level | IP65 |
| Operating Humidity | 10%~90% RH |
| Control Method | Synchronous, Asynchronous, 3G,WIFI,USB |
| Operating System | Win 98, Win2000, XP, Win7, Win8, Win10 |
| Video Signal Mode | RF, S-Video, RGB, RGBHV, YUV, YC etc |
| Certificate | CE, RoHS |
